7.00X10 4-101.6 ET-14.7 ATV & UTV WHEEL
7.00X10 4-101.6-71.5 ET-14.7
Rim size: 7.00x10
ET: -14.7
Centre hole diameter: 71.5
PCD: 101.6
ET: -14.7
Centre hole diameter: 71.5
PCD: 101.6
minimum order
200
Quantity
10 INCH ATV & UTV RIMS - SPECIFICATIONS
- Product name: Utv rim,atv rim,4 Lug 10 inch rims
- Rim size: 7.00x10
- Offset: -14.7
- Centre hole diameter: 71.5
- PCD: 101.6
- Stud hole: 4-14.5-60°
- Wheel Nut: M12X1.5 With conical shape 60°
- Recommended tyre size: 22X9-10
OTHER WHEEL SPECIFICATIONS
| RIM DIAMETER | WHEEL SIZE | RECOMMENDED TYRE SIZE | STUD HOLE | CENTRE HOLE DIAMETER（MM） | PCD (MM) |
| 10" | 4.00X10 | 5.00-10 | 5 | 72 | 114.3 |
| 5.00X10 | 23x7-10 | 4 | 60 | 100 | |
| 4 | 90 | 110 | |||
| 4 | 110 | 136 | |||
| 4 | 60 | 110 | |||
| 4 | 85 | 145 | |||
| 4 | 90 | 110 | |||
| 5.50X10 | 21x7-10 22X7-10 23x7-10 | 4 | 60 | 100 | |
| 4 | 60 | 110 | |||
| 4 | 90 | 110 | |||
| 4 | 115 LITHGT CENTER HOLE | 145 | |||
| 4 | LITHGT CENTER HOLE | 110 | |||
| 4 | 110 | 136 | |||
| 4 | 110 | 140 | |||
| 6.00X10 | 23X8-10 | 4 | 60 | 100 | |
| 4 | 72/75 | 101.6 | |||
| 5 | 72 | 114.3 | |||
| 5 | 94.5 | 140 | |||
| 7.00X10 | 22X9-10 | 4 | 72 | 101.6 | |
| 5 | 72 | 114.3 | |||
| 4 | 90 | 110 | |||
| 8.00X10 | 22X10-10 | 4 | 60 | 110 | |
| 4 | 90 | 110 | |||
| 4 | 110 | 136 | |||
| 4 | 85 | 145 | |||
| 4 | LITHGT CENTER HOLE | 140 |
