13 inch european trailer wheels

13 inch trailer rims

6.00JX13H2 5-112 STEEL WHEEL RIM FOR EUROPEAN TRAILER USE

6.00JX13H2 5-112-66.5 ET30

Rim size: 6.00Jx13H2
ET: 30
Centre hole diameter: 66.5
PCD: 112

minimum order

200

Quantity

Contact Now

13 INCH EUROPEAN TRAILER WHEELS - SPECIFICATIONS

Product name: Steel trailer rims,13 Inch trailer rims
Application: Car Trailer
Rim size: 6.00Jx13H2
Offset: 30
Centre hole diameter: 66.5
PCD: 112
Stud hole: 5-15.5-R12
Wheel Nut: M12X1.5 With spherical desigh R12
Recommended tyre size: 195/50R13C
Load carrying capacity: 900KGS@140KM/H

13 inch trailer rims

OTHER WHEEL SPECIFICATIONS

RIM DIAMETER	WHEEL SIZE	RECOMMENDED TYRE SIZE	STUD HOLE	CENTRE HOLE DIAMETER（MM）	PCD (MM)	OFFSET(MM)	DESIGN LOAD CAPACITY
13"	4.00JX13	145/70R13 145/80R13 155/70R13 155/80R13 165/70R13	4	58.5	98	30	500KGS@140KM/H
			4	57/60	100	30	500KGS@140KM/H
			5	66.5	112	30	500KGS@140KM/H
			4	85	115	0	500KGS@140KM/H
			4	85	130	0/20	500KGS@140KM/H
	4.50JX13	155R13 165R13 165/70R13 165/80R13 175/70R13 185/70R13	4	58.5	98	30	675KGS@140KM/H
			4	57/60.5	100	30	675KGS@140KM/H
			5	66.5	112	30	675KGS@140KM/H
			4	85	130	0/20	675KGS@140KM/H
			4	95.25	139.7	26	675KGS@140KM/H
			5	94	140	30	675KGS@140KM/H
	5.00JX13	175R13 185R13 175/70R13 185/70R13	4	58.5	98	30	750KGS@140KM/H
			4	57	100	30	750KGS@140KM/H
			5	66.5	112	30	750KGS@140KM/H
			4	85	130	0/20	750KGS@140KM/H
			5	94	140	30	750KGS@140KM/H
	5.50JX13	195/50R13C	4	58.5	98	30	900KGS@140KM/H
			4	57	100	30	900KGS@140KM/H
			5	66.5	112	30	900KGS@140KM/H
			4	85	130	0/20	900KGS@140KM/H
			4	95.25	139.7	32	900KGS@140KM/H
			5	94	140	30	900KGS@140KM/H
			5	115	165.1	7	900KGS@140KM/H
	6.00JX13	195/50R13C	4	58.5	98	30	900KGS@140KM/H
			5	66.5	112	30	900KGS@140KM/H
			5	115	165.1	7	900KGS@140KM/H
